Chhajed Steel Limited is engaged in manufacturing of high-quality stainless steel wires. Our manufacturing facility based in Maharashtra, India is capable of manufacturing stainless steel wires in extensive size range from 0.09 mm to 15 mm. Our wires division is well-equipped to manufacture high quality products having in-house facilities for solution annealing, bright annealing (continuous strand annealing), dry and wet wire drawing, high speed drawing, medium wire pattern laying, fine wire spooling, layer winding, random winding, TIG wire straightening and cutting facilities to name a few. We offer products as per ASTM, DIN, BS, JIS, NACE, AWS, GOST etc international standards and also as per specific customer requirements.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Stainless Steel Flanges

Specifications ASTM A580 ASME SA580 / ASTM A313 ASME SA313, AMS 5514
Stainless Steel Wires Group
  • Ferritic Stainless Steel
  • Austenitic Stainless Steel
  • Martensitic Stainless Steel
  • Duplex Stainless Steel
SS Wire Grades 304, 304L, 316, 316L, 17-4PH
Stainless Steel Wires Dimensions ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360
SS Wire Length Cut Lengths: 0.125" to 72"
No Limit on Spooled Lengths
304 SS Wires Diameter 0.0004" to 0.040"
10 microns to 1.0 mm
Other Sizes on Request
Wire Density 8.89 g/cm3
Ultimate Strength (≥ MPa) 580-750
Wire Resistance (μΩ.m) as standard
Wire Elongation (≥ %): 28-30
Surface Polished bright, Smooth, Bare, Enamel, PTFE, Ceramic, Plated
Tempers Tempers range from dead soft annealed to ultra spring temper
welded wire mesh Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch
Roll Length: 100feet or 150feet
wires mesh weaving methods plain weave, twill weave, dutch weave
304 / 316 Wire Technique Cold Rolled, hot rolled
304 / 316 Wire Condition M, Y, 1/2Hard
Offered in a wide range of packages including:
  • Spool
  • Reel
  • Coil
  • Bobbin
  • Carrier
  • Custom packaging provided from as low as 1lb to 200lb tapered plastics
Test Certificates
  • Wire Tensile Testing
  • 316 Wires Hardness Testing
  • Metallographic Inspection / Investigation
  • Corrosion Testing for Wires
  • Chemical Analysis for 316 Wires
  • Alloy Verification
  • 316 Wires Wrap Testing
  • Wire Elevated Temperature Testing
  • Stress Rupture Testing (Creep)
Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175

Chemical Properties of Stainless Steel Wires

Chemical Composition Specifications Designations Key Features Typical Applications
Element Min % Max %
C 0.07
Mn 2.00
P 0.045
S 0.030
Si 1.00
Cr 17.50 19.50
Ni 8.00 10.50
Fe BAL
ASTM A313
ASTM A580
BS 970
BS 2056
W.NR 1.4301
W.NR 1.4307
UNS S30400
AWS 161
Good mechanical properties and corrosion resistance. Springs.
Engineered components.
Wire mesh.
Wire cloth.
Hose braiding.

Physical Properties of Stainless Steel Wires

Condition Approx. tensile strength Approx. operating temperature
N/mm² ksi °C °F
Annealed 600 – 800 87 – 116 -200 to +300 -330 to +570
Spring Temper 1300 – 2200 189 – 319 -200 to +300 -330 to +570

Mechanical Properties of Stainless Steel Wires

Density 8.0 g/cm³ 0.289 lb/in³
Melting Point 1454°C 2650°F
Coefficient of Expansion 18.2 μm/m °C (20 – 100°C) 10.1 x 10-6 in/in °F (70 – 212°F)
Modulus of Rigidity 70.3 kN/mm² 10196 ksi
Modulus of Elasticity 187.5 kN/mm² 27195 ksi

Basic Type of Stainless Steel Wires

Stainless Steel Wires

Stainless Steel Wire

Stainless Steel Wires

SS Wire Mesh

Stainless Steel Wires

SS Ribbon Wire

Stainless Steel Wires

SS Wire Rope

Stainless Steel Wires

SS Filler Wire

Stainless Steel Wires

ASTM A302 SS Spring Wire

Stainless Steel Wires

Galvanised SS Wire

Stainless Steel Wires

1.5 MM SS Diameter Wire

Stainless Steel Wires

SS 430 Tig Welding Wire
