Copper Nickel 90/10 Sheets & Plates
Copper Nickel 90/10 Sheets & Plates Manufacturers in Mumbai, Copper Nickel 90/10 Sheets & Plates Suppliers in Mumbai, Copper Nickel 90/10 Sheets & Plates Stockists in Mumbai, Copper Nickel 90/10 Sheets & Plates Exporters in Mumbai
Copper Nickel Plate are possesses good creep resistance and average high strength and at high temperatures, they are excellent corrosion resistance even in marine environments. They are costs more in comparison to copper-aluminum alloys and other alloys with similar mechanical properties. C70600 Plate is suitable for marine condenser tube installations in place of aluminum brass, especially where higher water velocities are encountered. Oxyacetylene welding, soldering, coated metal arc welding, brazing, gas shielded arc welding. Copper Nickel 90/10 Plate is good with the recommended hot working temperature ranging between 760 and 816°C in hot working capacity.
Cuni 90/10 Sheet used in applications where chloride stress-corrosion cracking precaution prevents usage of stainless steels and which requires high corrosion resistance. It is primarily used for seawater service as machined and forged valve and pump components, fittings and hardware. Cu-Ni 90/10 Plate is inherently antimicrobial which makes it a good choice for touch surface applications. They are also known as ASTM B122 UNS C70600 is a copper-nickel alloy that offers well resistant to stress corrosion. It is often used when an application will involve high-velocity seawater, due to the addition of small amounts of iron and manganese. 90 10 Cu Ni Plate in the chemical and marine industries which include tubes and tub sheets for evaporators, condensers and heat exchangers.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of Copper Nickel 90/10 Sheets & Plates
| 90/10 Copper Nickel Sheet ASTM Specification |
ASTM B122 UNS C70600, ASME SB122 |
| Copper Nickel Plate Specification |
MSRR, AMS, BS, ASTM B122 / ASME SB122 |
| Copper Nickel 90/10 Plate Length & Sizes |
1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2m, 2.44m, 3m, 36" X 120" or 48" X 144", Cut to size available |
| Thickness |
0.1mm to 100 mm Thk |
| Cuni 90/10 Sheet Width |
10-2500mm |
| ASTM B122 UNS C70600 Plate AMS |
AMS |
| 90 10 Cu Ni Plate Hardness |
Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Temper |
Annealed |
| Condition |
Polished on both sides |
| Cu Ni 90 10 Plate Finish |
Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| C70600 Plate Stock in form of |
Cupro Nickel 90/10 Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate Manufacturer and Supplier |
| High Quality 90/10 Cupro Nickel Plate |
- Huge Stock, Timely delivery
- Raw Materials Certificate
- EN 10204/3.1B
- 100% Radiography Test Report
- High special strength, high melt point
- Third Party Inspection Report, etc
- Excellent corrosive resistance, good thermal resistance
- Customer support after-sales service
- Strict Control from Raw Material to Finished Copper Nickel 90/10 Plate
|
| ASTM B122 UNS C70600 profiling |
To provide a full profiling service we use numerous profiling methods including:
- Plasma Plate Cutting
- Laser Plate Cutting
- Oxy-propane Flame Cutting
|
| Specialized in |
- Copper Nickel 90/10 Sheet: material under 3/16" [5.00 mm] in thickness and 24" [600 mm] and over in width
- Copper Nickel 90/10 Plate: material 3/16" [5.00 mm] and over in thickness and over 10" [250 mm] in width
- Copper Nickel 90/10 Strip: cold-rolled material under 3/16" [5.00 mm] in thickness and under 24" [600 mm] in width
- Copper Nickel 90/10 Clad plate: Copper Nickel 90/10 Clad plate is a composite steel plate made by bonding Copper Nickel 90/10 plate, etc.
- Free Quote, Inquiry answered within 24 hours
|
Chemical Properties of Copper Nickel 90/10 Sheets & Plates
| Grade |
Cu |
Mn |
Pb |
Ni |
Fe |
Zn |
| Cupro Nickel 90/10 |
88.6 min |
1.0 max |
0.05 max |
9-11 max |
1.8 max |
1 max |
Mechanical Properties of Copper Nickel 90/10 Sheets & Plates
| Element |
Copper Nickel 90/10 |
| Density |
8.1 g/cm3 |
| Melting Point |
1443 °C (2430 °F) |
| Tensile Strength |
Psi -80,000, MPa -551 |
| Yield Strength (0.2%Offset) |
Psi - 35,000, MPa - 241 |
| Elongation |
30 % |
Equivalent Standard of Copper Nickel 90/10 Sheets & Plates
| STANDARD |
WERKSTOFF NR. |
UNS |
| Cupro Nickel 90/10 |
2.0872 |
C70600 |
