Titanium Tubes

Titanium Tubes, Titanium Tubes Manufacturers, Titanium Tubes Suppliers, Titanium Tubes Stockists, Titanium Tubes Exporters

Titanium Tubes Manufacturers In India, Titanium Tubes Suppliers In India, Titanium Tubes Stockists In India, Titanium Tubes Exporters In India

Titanium Grade 2 Tubes

Titanium Tubes

Titanium Tubes Manufacturers in Mumbai, Titanium Tubes Suppliers in Mumbai, Titanium Tubes Stockists in Mumbai, Titanium Tubes Exporters in Mumbai

Chhajed Steel & Alloy Pvt Ltd is one of the leading titanium tube suppliers. We offer a wide range of titanium seamless pipes and titanium welded pipes. It can be available in customized dimensions, sizes, & specifications. Titanium Welded Tubes is a strong metal with low density that is quite ductile especially in an oxygen-free environment and it is lustrous, and metallic-white in color. It is produced through roll forming strips or sheets into a tube shape and then welding it into seam longitudinally. It can be skilled either by hot forming and cold forming processes. As compared to hot forming, cold forming results in smoother finishes and tighter tolerances.

Titanium Tube is resistant to corrosion in sea water and chlorine. It is alloyed with iron, vanadium, aluminum, and molybdenum among other elements to produce strong, lightweight alloys for industrial purpose such as chemical, desalination plants, petrochemicals, paper and pulp. For aerospace purpose such as jet engines, spacecraft and missiles.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Titanium Tubes

Standard ASTM, AISI, GB, JIS, customers' requests available
Size Round Tube: OD: 16-119mm or customized
Thickness 0.25mm-3.0mm
Length 6m or according to customers' request
Sample Free sample is available, but freight should be paid by you
Tolerance Outer diameter: ±0.2mm
Thickness: ±0.05mm
Length: ±0.5mm
Ends In plain end or bevelled ends or as your requirements
Welding Line Type ERW (Electrical Resistance Weld)
Finishing A. Sanded
B. Gloss #400,Mirror #600 - #1000
C. Brushed
D. Wood Grain
E. Embossed, Threaded
Application Decorations, constructions, food industry, etc.
Certification ISO, SGS
Round Pipe Size 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm
Square Pipe Size 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm
Rectangle Pipe Size 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm
Thickness exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm
Length 6m or according to customer's request
Outer diameter 6.35-219mm
Tolerance Outer diameter :±0.2mm
Thickness :±0.02mm
Length :±0.5mm
Process method Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished
Test Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector
Equipment Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc
Test Certificates Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Chemical Properties of Titanium Tubes

Grade Ti C Fe H N O Al V
Ti Grade2 99.2 min 0.1 max 0.3 max 0.015 max 0.03 max 0.25 max
Ti Grade5 90 min 0.25 max 0.2 max 6 min 4 min

Mechanical Properties of Titanium Tubes

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Titanium Gr. 2 4.5 g/cm3 1665 °C (3030 °F) Psi – 49900 , MPa – 344 Psi – 39900 , MPa – 275 20 %
Titanium Gr. 5 4.43 g/cm3 1632 °C (2970 °F) Psi – 138000 , MPa – 950 Psi – 128000 , MPa – 880 14 %

Equivalent Standard of Titanium Tubes

STANDARD WERKSTOFF NR. UNS
Titanium Gr. 2 3.7035 R50400
Titanium Gr. 5 3.7165 N56400

Basic Type of Titanium Tubes

Titanium Tubes

Titanium Seamless Tube

Titanium Tubes

AISI Titanium Welded Tube

Titanium Tubes

ANSI Titanium Tube

Titanium Tubes

Titanium Schedule 40 Tube

Titanium Tubes

Titanium ERW Tube

Titanium Tubes

Pure Titanium Round Tube
