JIS G3101 SS400 Mild Steel Plate is popular for proper tensile strength and toughness, good plasticity, welding performance, and processing property. It is widely used for numerous industries and applications and due to its excellent performance and quality, it is considered among the best steel grade. SS400 steel is the most commonly used hot-rolled structural steel (formerly known as SS41) in Japan and is called general structural rolled steel in JIS G3101. SS400 material is cheap and versatile and plays an important role in construction, bridges, civil engineering, and mechanical equipment structures.
SS400 Steel meaning: SS is the abbreviation of Steel Structure, 400 means that the tensile strength is ≥ 400 MPa. SS41 Meaning: 41 means that the tensile strength is 41kgf/mm2 or higher. If the thickness is 40 mm or more, the positive side tolerance can be relaxed through mutual negotiation. The width and thickness tolerance of 5000 mm depends on the agreement between the two parties. SS400 Mild Steel Cr Plates covers carbon structural steel shapes, plates, and bars of structural quality for use in riveted, bolted, or welded construction of bridges and buildings, and for general structural purposes. Steel plate sheet SS400 has some features like its heat condition, excellent freezing, even structure with pressure resistance, and its good mechanical properties.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of JIS G3101 SS400 Mild Steel Plate Sheets & Plates
| Specifications |
ASTM / ASME |
| Standard |
AISI, ASTM, BS, DIN, GB, JIS |
| Thickness |
6MM to 300MM, |
| Specialize |
Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Length |
3000mm to 15000mm |
| Form |
Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish |
Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness |
Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade |
MS SS400 |
Chemical Composition of JIS G3101 SS400 Mild Steel Plate Sheets & Plates
| Grade |
Fe |
Si |
C |
S |
P |
| SS400 |
min. |
99.25 |
– |
– |
– |
– |
| max. |
100 |
0.4 |
0.26 |
0.050 |
0.040 |
Mechanical Composition of JIS G3101 SS400 Mild Steel Plate Sheets & Plates
| Grade |
Yield Strength
min.
(Mpa) |
Tensile Strength
(Mpa) |
Elongation min. % |
Impact Resistance min.[J] |
Thickness
＜16 mm |
Thickness
≥16mm |
Thickness |
Thickness |
Thickness |
| ＜5mm |
5-16mm |
≥16mm |
| SS400 |
245 |
235 |
400-510 |
21 |
17 |
21 |
– |
Equivalent Material Grade of JIS G3101 SS400 Mild Steel Plate Sheets & Plates
| SS400 Equivalent Steel Grade |
| Japan |
US |
European Union |
ISO |
China |
Canada |
India |
| JIS G3101 |
SS400 |
ASTM A36 |
A36 steel |
EN 10025-2 |
S235 (S235JR) |
ISO 630 |
S235 |
GB/T 700 |
Q235 |
CSA G40.21 |
44W (300W) |
IS 2062 |
E250 |
Basic Type of JIS G3101 SS400 Mild Steel Plate Sheets & Plates
