Stainless Steel 316L Round Bars
Stainless Steel 316L Pipes Manufacturers in Mumbai, Stainless Steel 316L Pipes Suppliers in Mumbai, Stainless Steel 316L Pipes Stockists in Mumbai, Stainless Steel 316L Pipes Exporters in Mumbai
Stainless Steel 316L Round Bar manufactured from a strong corrosion-resistant material high on chromium content. It has excellent toughness, even down to cryogenic temperatures. It has excellent toughness, even cryogenic temperatures, and it also offers higher creep, stress to rupture, and tensile strength at elevated temperatures.
They are strong corrosion-resistant material and high chromium content in the steel rods forms a layer of chromium oxide on the surface that protects staining and corrosion caused by steam, air, and water. Stainless Steel 316L Round Bar is the common austenitic stainless steel, they also come in billet form and generally includes a cross-section based on the shape of rod or bar stock.
Stainless Steel 316L flat bar is easier to machine compared to 316 stainless steel due to its lower carbon content. They are broadly used for industrial tools, ornamental fence construction, structure construction, mechanical parts. Optimal hot working temperatures should be in the range 1150-1260 °C, and certainly should not be less than 930°C. A479 type 316L is the technical document that outlines the requirements for stainless steel hot/cold-finished bars.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of Stainless Steel 316L Round Bar
| Specification |
ASTM A276/ A479, ASME SA276/SA479 |
| Grade |
Stainless Steel 316L (UNS S31603) |
| Flat bar size |
1/2" to 10" in thickness range of 2mm to 150mm |
| Square bar size |
18mm – 47mm (11/16″ to 1-3/4″) |
| Hollow Bar |
32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Hex Bar size |
18mm – 57mm (11/16″ to 2-3/4″) |
| Bright Bar |
Outside Diameter in the range of 4mm to 100mm |
| Round bar size |
Outside Diameter in the range of 4mm to 500mm |
| Channel Bar |
80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Angle bar size |
3mm*20mm*20mm~12mm*100mm*100mm |
| Billet Size |
1/2″ to 495mm Diameter |
| Rectangular bar Size |
33 x 30mm to 295 x 1066mm |
| Finish |
Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance |
H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients' requirements |
| Surface |
Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition |
Hardened & tempered, annealed |
| Technique |
Stainless Steel 316L Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing |
Bar cutting to 650mm |
| Section |
3.0 to 12.0mm thickness |
| Form |
Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Our Stainless Steel 316L Round bar conforms to NACE MR0175/ISO 15156 |
Chemical Properties of Stainless Steel 316L Round Bar
| Grade |
C |
Mn |
Si |
P |
S |
Cr |
Mo |
Ni |
N |
| SS 316L |
0.3 max |
2 max |
0.75 max |
0.045 max |
0.030 max |
16 – 18 |
2 – 3 |
10 – 14 |
0.10 max |
Mechanical Properties of Stainless Steel 316L Round Bar
| Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| 8.0 g/cm3 |
1454 °C (2650 °F) |
Psi – 75000 , MPa – 515 |
Psi – 30000 , MPa – 205 |
40 % |
Equivalent Standard of Stainless Steel 316L Round Bar
| STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
BS |
GOST |
AFNOR |
EN |
| SS 316L |
1.4404 / 1.4435 |
S31603 |
SUS 316L |
316S11 / 316S13 |
03Ch17N14M3 / 03Ch17N14M2 |
Z3CND17‐11‐02 / Z3CND18‐14‐032 |
X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Basic Type of Stainless Steel Round Bar
ASTM A276 316L SS Hex Bar
