IS 4923 YST 210 Hollow Section Pipes

IS 4923 YST 210 Hollow Section Pipes, IS 4923 YST 210 Hollow Section Pipes Manufacturers, IS 4923 YST 210 Hollow Section Pipes Suppliers, IS 4923 YST 210 Hollow Section Pipes Stockists, IS 4923 YST 210 Hollow Section Pipes Exporters

IS 4923 YST 210 Hollow Section Pipes Manufacturers In India, IS 4923 YST 210 Hollow Section Pipes Suppliers In India, IS 4923 YST 210 Hollow Section Pipes Stockists In India, IS 4923 YST 210 Hollow Section Pipes Exporters In India

IS 4923 Square Tube, IS 4923 Rectangular Hollow Sections manufacturer in India

IS 4923 YST 210 Hollow Section Pipes Manufacturers in Mumbai, IS 4923 YST 210 Hollow Section Pipes Suppliers in Mumbai, IS 4923 YST 210 Hollow Section Pipes Stockists in Mumbai, IS 4923 YST 210 Hollow Section Pipes Exporters in Mumbai

IS 4923 Pipe is a Carbon Steel IS 4923 YST 240 Seamless Pipes which has unique composition and mechanical properties, they are also depended on ISO standards bearing 0.12% max. Carbon, 0.50% max. IS 4923 Rectangular Hollow Sections have high heat tolerance property, as they are used in hoisted temperature conditions. IS 4923 Square Hollow Sections are highly non-corrosive property, and pipes are considered for use in the for mentioned industries. It obeys certain Min. Min. Tensile Strength Mpa upto 310 and Min. Weldability, Packing and identification information includes bundled by sealing metal strap and each bundle is labeled for measurement, size, lot number with approximate weight of each bundle 1.5 Mt (+/-500 kg) and weldable with standard M.S. Electrodes without any pre-heating.

Square and Rectangular specified ASTM A500 IS 4923 Pipe base carbon steel tends to be much higher. Minimum copper content added in this particular steel grade is optional. Carbon steel based IS 4923 YST 210 pipes used mainly for structural purposes and are used in the transportation of various media. IS 4923 Square Tube are most preferred amongst other grades since these pipes are able to perform well under such conditions. They are useful in conveying fluids like water, oil or chemicals along with gases, air and steam from the on-site. IS 4923 Hollow Section is more appreciated for the use, specially in demanding operations.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of IS 4923 YST 210 Hollow Section Pipes

Indian Standard	IS 4923 YST 210
Size range	20 x 20mm TO 400 x 400mm
Wall Thickness (WT)	0.5 - 25mm
Length	6.0 m ± 0.05 m Customized length ranging from 6 m to 11 m
Type	Seamless/ Welded / EFW / ERW
Dimensions Tolerances	Thickness : (All sizes +/- 10%)
Outside Dimension (OD) of sides	+/-1% with a minimum of +/-0.50 mm
Squareness of Corners	90 degree +/-2 degree
Radius of Corners	3 t, Max where t is the thickness of the section.
Concavity / Convexity	1 percent of the size
Twist Tolerance	Maximum 2 mm ± 0.05 mm/m length-measured relative vertical shift of any adjacent corner of the section, measured by keeping one side on flat surface
Pipe End Finish	Plain ended-Mechanically sheared, mill-cut finish without further machining
Export Packing	In bundles, Varnish coating, Ends can be bevelled or square cut, Anticorrosion heat preservation, End Capped Certification & supplementary test, Finishing & Identity Mark
Surface Finish	Black without any surface treatment of oiling or varnishing.

Chemical Properties of IS 4923 YST 210 Hollow Section Pipes

Specification	Steel Grade	C	Si	Mn	P	S
IS 4923	YST 210	0.12% max.	0.03% to 0.08%	0.50% max.	0.05% max.	0.05% max.

Mechanical Properties of IS 4923 YST 210 Hollow Section Pipes

Grade	Min. Tensile Strength Mpa	Min. Yield Stress Mpa	Min. Elongation Percent for size
Grade	Min. Tensile Strength Mpa	Min. Yield Stress Mpa	25.4 and under	over25.4
YST 210	330	210	12	20

Available Sizes of IS 4923 YST 210 Hollow Section Pipes

Sizes (mm)	kg/m	Sizes (mm)	kg/m
20 x 20 x 2.0	1.12	20 x 20 x 2.5	1.35
25 x 25 x 1.5	1.06	25 x 25 x 2.0	1.43
25 X 25 X 2.5	1.74	25 X 25 X 3.0	2.04
30 X 30 X 2.0	1.68	30 X 30 X 2.5	2.14
30 X 30 X 3.0	2.51	40 x 40 x 1.5	1.81
40 x 40 x 2.0	2.31	40 x 40 x 2.5	2.92
40 x 40 x 3.0	3.45	40 x 40 x 4.0	4.46
40 x 40 x 5.0	5.40	50 x 50 x 1.5	2.28
50 x 50 x 2.0	2.93	50 x 50 x 2.5	3.71
50 x 50 x 3.0	4.39	50 x 50 x 4.0	5.72
50 x 50 x 5.0	6.97	60 x 60 x 3.0	5.34
60 x 60 x 4.0	6.97	60 x 60 x 5.0	8.54
60 x 60 x 6.0	9.45	70 x 70 x 3.0	6.28
70 x 70 x 3.6	7.46	70 x 70 x 5.0	10.11
70 x 70 x 6.3	12.50	70 x 70 x 8	15.30
75 x 75 x 3.0	7.07	80 x 80 x 3.0	7.22
80 x 80 x 3.6	8.59	80 x 80 x 5.0	11.70
80 x 80 x 6.0	13.90	90 x 90 x 3.0	8.01
90 x 90 x 3.6	9.72	90 x 90 x 5.0	13.30
90 x 90 x 6.0	15.76	90 x 90 x 8.0	20.40
100 x 100 x 3.0	8.96	100 x 100 x 4.0	12.00
100 x 100 x 5.0	14.80	100 x 100 x 5.0	14.80
100 x 100 x 6.0	16.19	100 x 100 x 8.0	22.90
100 x 100 x 10	27.90	120 x 120 x 5	18.00
120 x 120 x 6.0	21.30	120 X 120 X 6.3	22.30
120 x 120 x 8.0	27.90	120 x 120 x 10	34.20
120 X 120 X 12	35.8	120 X 120 X 12.5	41.60
140 X 140 X 5.0	21.10	140 X 140 X 6.3	26.30
140 X 140 X 8	32.90	140 X 140 X 10	40.40
140 X 140 X 12.5	49.50	150 X 150 X 5.0	22.70
150 X 150 X 6.3	28.30	150 X 150 X 8.0	35.40
150 X 150 X 10	43.60	150 X 150 X 12.5	53.40
150 X 150 X 16	66.40	150 X 150 X 16	66.40
180 X 180 X 5	27.40	180 X 180 X 6.3	34.20
180 X 180 X 8	43.00	180 X 180 X 10	53.00
180 X 180 X 12.5	65.20	180 X 180 X 16	81.40
200 X 200 X 5	30.50	200 X 200 X 6	35.8
200 x 200 x 6.3	38.2	200 x 200 x 8	48.00
200 x 200 x 10	59.30	200 x 200 x 12.5	73.00
200 x 200 x 16	91.50	250 x 250 x 6.3	48.10
250 x 250 x 8	60.50	250 x 250 x 10	75.00
250 x 250 x 12.5	92.60	250 x 250 x 16	117.00
300 x 300 x 6.3	57.90	300 x 300 x 8	73.10
300 x 300 x 10	57.90	300 x 300 x 8	90.70
300 x 300 x 12.5	112.00	300 x 300 x 16	142.00
350 x 350 x 8	85.70	350 x 350 x 10	106.00
350 x 350 x 12.5	132.00	350 x 350 x 16	167.00
400 x 400 x 10	122.00	400 x 400 x 12	141.00
400 x 400 x 12.5mm	152.00	400 x 400 x 16	192

Basic Type of IS Pipes

IS 4923 YST 210 Hollow Section Pipe

IS 4923 YST 210 Hollow Section Seamless Pipe

IS 4923 YST 210 Hollow Section Welded Pipe

IS 4923 Square Hollow Sections

IS 4923 Rectangular Hollow Sections

IS 4923 YST 210 Hollow Section
