Chromoly Sheets & Plates

Chromoly Sheets & Plates, Chromoly Sheets & Plates Manufacturers, Chromoly Sheets & Plates Suppliers, Chromoly Sheets & Plates Stockists, Chromoly Sheets & Plates Exporters

Chromoly Sheets & Plates Manufacturers In India, Chromoly Sheets & Plates Suppliers In India, Chromoly Sheets & Plates Stockists In India, Chromoly Sheets & Plates Exporters In India

Chromoly Sheets & Plates

Chromoly Sheets & Plates Manufacturers in Mumbai, Chromoly Sheets & Plates Suppliers in Mumbai, Chromoly Sheets & Plates Stockists in Mumbai, Chromoly Sheets & Plates Exporters in Mumbai

Chromoly Sheets & Plates Plate has excellent strength-to-weight ratio and tensile strength which makes it highly suitable to design high-end bicycle frames, aircraft fuselages, and racing car chassis. They are more durable and considerably stronger than standard steel and it is often used in applications where high strength is needed. Its hardenability and resistance to corrosion can be increased by the additional chrome and its toughness and resistance to temperature can be increased by the addition of molybdenum.

Because of high tensile strength, fabricators can utilize less of the steel to reduce weight, without compromising with the strength or quality of the final element. Chrome Molybdenum Steel Plate needs to be preheated prior to welding but this is not necessary if the sheet is less than 3 mm thickness. That can be welded by using MIG or TIG welding techniques. Although TIG welding is more fast, effective, and cleaner than MIG welding. When it is annealed it provides good machining and weldability properties.

Chrome Moly Plate offers better strength-to-weight ratio and higher ductility than carbon steels and it is also a more cost-effective than carbon fibre or titanium plates. They are useful high-end race cars and bikes which reduce its weight can convert to an all-important and increase it performance and speed. Chrome Moly Steel Plate hardening is very beneficial because it reduces wear and tear over the lifetime of use. It can be easily hardened by heat treating or work hardening.

By the process carburization it can also be case-hardened, where the outer side of the metal is outstandingly hardened in the same time the material retains its chemical properties. Through heat or work hardening the hardness ability to can be increased. Chrome Moly Steel Plate can be used for manufacturing excellent elements such as crankshafts and pistons which undergoes tough usage.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Chromoly Sheets & Plates

Trade Name Chrome Molybdenum steel, Chromemoly
Thickness up to 100mm
Width up to 2500mm
Length 1200 Meters, Custom Cut Lengths
Specification
  • ASTM A829 grade 4130
  • ASTM A829 Grade 4140
  • ASTM/ ASME SA/ A 387 - Gr.11 Cl.2, Gr.5 Cl. 2, Gr.22 Cl.2, Gr.12 Cl.2
  • BS EN 10028-2 - 13 CrMo Si 5-5, 16Mo3, 10 CrMo 9-10, 13 CrMo 4-5
  • BS 1501 2 / BS 1501 621B/ BS 1501 620B
  • AMS 6345 Plate/ Sheet (Normalised)
  • AMS 6351: Plate/ Sheet (spheroidised)
  • AMS 6350: Plate/ Sheet (Annealed)

Chemical Properties of Chromoly Sheets & Plates

Standard Grade Carbon Sulphur Manganese Phosphorus Chromium Silicon Molybdenum
ASTM A29 4130 (G41300) 00.28-0.33 00.040 00.40-0.60 00.035 00.80-1.10 00.15-0.35 00.15-0.25
EN 10250
/ EN 10083
25CrMo4/
1.7218
00.22-0.29 00.035 00.60-0.90 00.025 00.90-1.2 ≦0.40 00.15-0.30
JIS G4105 SCM430/
SCM2
00.28-0.33 00.030 00.60-0.85 00.030 00.90-1.2 00.15-0.35 00.15-0.30

Mechanical Properties of Chromoly Sheets & Plates

Mechanical Properties Metric English
Tensile Yield Strength 435 MPa 63100 psi
Ultimate Tensile Strength 670 MPa 97200 psi
Modulus of Elasticity 205 GPa 29700 ksi
Rockwell B Hardness 92 92
Elongation at Break 25.50% 25.50%

Equivalent Standard of Chromoly Sheets & Plates

Origin USA Japan BS BS
Standards ASTM A29 JIS G4105 EN 10083/ EN 10250 BS 970
Grade 4130 SCM430 25CrMo4/1.7218 708A25/708M25

Basic Type of Chromoly Sheets & Plates

Chromoly Sheets & Plates

Chromoly Sheets & Plates Sheets

Chromoly Sheets & Plates

AISI Chromoly Sheets & Plates Plates

Chromoly Sheets & Plates

ANSI Chromoly Sheets & Plates Sheets

Chromoly Sheets & Plates

Chromoly Sheets & Plates Strips

Chromoly Sheets & Plates

Chromoly Sheets & Plates Coil

Chromoly Sheets & Plates

Pure Chromoly Sheets & Plates Plates
