Among the elements of 1431 Grade 350wa, carbon is hardening element. Manganese is the important austenite stabilizing elements which contribute to the formation of texture structure and increase the strength, firmness and wear resistance. Silicon helps to strengthen the material strength. Phosphorus in its element reduces the plasticity and toughness and appearing cold brittleness.

1431 Grade 350wa can significantly increase the strength of it, and improve the atmospheric corrosion stability. 1431 Gr 300wa can be heat treated at 1513°C - 1321°C, its application is for weldable structural steels. 1431 Gr 300w know for offering great strength though it is light in weight. It has high strength, low weight, ductility, durability and resistance to corrosion.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Chemical Properties of SABS SABS 1431 Grade 300wa Sheets & Plates

Maximum chemical composition1)
Grade C Mn Si P S Nb V Nb + V Al Cu1) Ni2) Cr2) Mo2) Normal supply conditions
240WA 0.22 1.60 0.50 0.040 0.050 0.01 0.03 0.04 0.10 0.35 0.30 0.30 0.10 As rolled
240WC 0.22 1.60 0.50 0.040 0.050 0.01 0.03 0.04 0.10 0.35 0.30 0.30 0.10 As rolled
240WDD 0.22 1.60 0.50 0.040 0.040 0.10 0.10 0.10 0.10 0.35 0.30 0.30 0.10 Normalised
300WA 0.22 1.60 0.50 0.040 0.050 0.03 0.03 0.04 0.10 0.35 0.30 0.30 0.10 As rolled
300WC 0.22 1.60 0.50 0.040 0.050 0.03 0.03 0.04 0.10 0.35 0.30 0.30 0.10 As rolled
300WDD 0.22 1.60 0.50 0.040 0.040 0.10 0.10 0.10 0.10 0.35 0.30 0.30 0.10 Normalised
350WA 0.22 1.60 0.50 0.040 0.040 0.10 0.10 0.10 0.10 0.35 0.30 0.30 0.10 As rolled
350WC 0.22 1.60 0.50 0.040 0.040 0.10 0.10 0.10 0.10 0.35 0.30 0.30 0.10 As rolled < 16 mm thick
Normalised3)
> 16mm
350WDD 0.22 1.60 0.50 0.040 0.040 0.10 0.10 0.10 0.10 0.35 0.30 0.30 0.10 Normalised

Mechanical Properties of SABS SABS 1431 Grade 300wa Sheets & Plates

Grade Tensile
strength
(MPa)		 Min yield strength (MPa) for thickness t (mm) Elongation % (min) on gauge length of Charpy V-notch impact test
3<t<16 16<t<40 40<t<63 63<t<80 50 mm 200 mm 5.65 So Avrage
impact
resistance J (min)		 Test
Tempe-
rature
(oC)		 Thickness
(max)
(mm)
240WA 380/510 240 240 230 220 28 20 22 - - -
240WC 380/510 240 240 230 220 28 20 22 27 0 80
240WDD 380/510 240 240 230 220 28 20 22 27 -30 80
300WA 450/620 300 300 290 280 24 20 22 - - -
300WC 450/620 300 300 290 280 24 20 22 27 0 63
300WDD 450/620 300 300 290 280 24 20 22 27 -30 63
350WA 480/650 350 350 340 325 22 18 20 - - -
350WC 480/650 350 350 340 325 22 18 20 27 0 80
350WDD 480/650 350 350 340 325 22 18 20 27 -30 80

Equivalent Standard of SABS SABS 1431 Grade 300wa Sheets & Plates

American (USA) Standards

 Europe (EN) Standards

 Japan Standards

 South Africa Standards

 Yield Stress

 Tensile Strength
 Lower Strength (for workability and weldability)
 ASTM A283 gr. C EN 10025 S235JR
DIN 17100 RSt 37-2
BS 4360: gr. 40 A/B/C 		 JIS G3101 SS 330  1431 gr. 240 W A/C  235 MPa min  340-470Mpa
Normal Strength (for general use)
ASTM A36 EN 10025 S275 JR
DIN 17100 RSt 44-2
BS 4360: gr. 43 A/B/C		 JIS G3101 SS400 1431 gr. 300 W A/C  275 MPa min  430-550 MPa
 Higher Strength Microalloyed Steel Plate
ASTM A572 gr. 50 EN 10025 S355JR
DIN 17100 RRSt 52-2
BS 4360: gr. 50 A/B/C   		 JIS G3101 SS490  1431 gr. 350 W A/C  355 MPa min  490-630 MPa
 Weathering Steel Plate (for improved corrosion resistance)


 Other Standards




    COR-TEN/ A

  345 MPa min  480 MPa min
