| Standard Specifications |
ASTM A182 / A240 & ASME SA182 / SA240 |
| Dimensions |
ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Standard |
- BS (British Standard)
- BS1560-3.1
- API 7S-15
- ASA/ANSI/ASME B16.5/16.36/16.47A/16.47B
- B16.47 Series A & B
- B16.48
- API 605
- BS4504
- BS 10
- DIN, EN (European)
- EN-1092
- GOST Flange
- MSS S44
- ISO 70051
- JIS B2220
- API 7S-43
- EN 1092
|
| Size / Range |
1/2 inch (15 NB) - 48 inch (1200NB) DN10~DN5000 or special sizes |
| Connect Type/ Flange Face Type |
Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove Manufacturer and Supplier |
| Pressure Rating ANSI |
Class 150, 300, 600, 900, 1500, 2500 |
| Pressure Calculation in DIN |
6Bar 10, 16, 25, 40 and PN6 PN10 PN16 PN25 PN40, PN64 |
| JIS |
5K, 10, 16 20, 30, 40, 63 |
| UNI |
6Bar, 10, 16, 25, 40 |
| EN |
6Bar, 10, 16, 25, 40 |
| Most common types of |
Threaded, Screwed, Plate, Forged |
| Manufacturer Test Certificates |
EN 10204 3.1B
Third Party Inspection Report
100% Radiography Test Report
Raw Materials Certificate |
| Production technique |
- Forged, Heat treated and machined
|
| Special design |
As per your drawing
AS, ANSI, BS, DIN and JIS
15 NB (1/2 In) - 200 NB (8 In)
Equal and Reducing Configurations
|
| Origin |
Indian, West Europe, Korean USA, Japan, |
| Uses & application |
- Power generation
- Oil refinery industry
- Petrochemical
- Petrochemical industry
|
| Pipe Marking |
All SS 304 Flanges are marked as follows: Supplier or Manufacturer's Name, NPS, Flange Class, ASME B16.5, Material Specification, Trade mark |
| Flange manufactured as per |
- American standard (ANSI)
- German (DIN)
- AS 2129: Table D; E; H
- B.S: BS3293, BS4504 , BS1560, BS10
- ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
- ANSI : ANSI B16.5, ANSI B16.47(API605), MSS SP44, ANSI B16.36, ANSI B16.48
- ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
- British standard (BS)
- DIN: 2631, 2527, 2638, 2641, 2642, 2656, 2627, 2635, 2632, 2566, 2573, 2576, 2633, 2634, 2628, 2655, 2629, 2637, 2636
- The other standard: AWWA C207; KS B1503, EN1092-1, GOST12820, JIS B2220; SABS1123; NFE29203; UNI2276
|
