Hastelloy C22 Plate is a versatile austenitic nickel-chromium-molybdenum-tungsten alloy with enhanced resistance to pitting, stress corrosion cracking, and crevice corrosion. It has chromium content which provides good oxidizing resistance media while the tungsten and molybdenum content provides good resistance reduction to media. ASME SB575 C22 Hastelloy Coil is beneficial for multi-purpose plants where such "upset" condition usually occurs, they optimum resistance to an environment where oxidizing and reducing conditions in process streams are encountered. Alloy C22 Plate has excellent resistance to oxidizing aqueous media including mixtures containing nitric acid and wet chlorine or oxidizing acids with chlorine ions.

UNS N06022 Hot Rolled Plate is useful in applications for Pesticide production, flue gas scrubbers, sulfur dioxide scrubbers, pulp and paper bleach plants, chlorination systems, and chemical processing industry in pickling systems. JIS NW 6022 Plate is ductile enough to be formed by cold working and due to work hardening intermediate annealing, it should be performed at a temperature range between 2020-2150° F followed by a rapid quench. Stockiest of Alloy C22 Hastelloy Foil suitable for most chemical process applications in the as-welded condition. They weld heat-affected zone it resists the formation of grain-boundary precipitates.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of Hastelloy C22 Sheets & Plates

Specifications ASTM B575 / ASME SB575
Standard ASTM, ASME and API
Specialize Shim Sheet, Perforated Sheet, B. Q. Profile.
Size 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)
Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Grade Hastelloy C22 (UNS N06022)

Chemical Properties of Hastelloy C22 Sheets & Plates

Grade C Mn Si S Co Ni Cr Fe Mo P
C22 0.010 max 0.50 max 0.08 max 0.02 max 2.50 max 50.015 min* 20.00 – 22.50 2.00 – 6.00 12.50 – 14.50 0.02 max

Mechanical Properties of Hastelloy C22 Sheets & Plates

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Hastelloy C22 8.69 g/cm3 1399 °C (2550 °F) Psi – 1,00,000 , MPa – 690 Psi – 45000 , MPa – 310 45 %

Equivalent Standard of Hastelloy C22 Sheets & Plates

STANDARD WERKSTOFF NR. UNS JIS GOST EN OR
Hastelloy C22 2.4602 N06022 NW 6022 NiCr21Mo14W
