EN 10083-2 C45E Carbon Steel Pipes

EN 10083-2 C45E Carbon Steel Pipes, EN 10083-2 C45E Carbon Steel Pipes Manufacturers, EN 10083-2 C45E Carbon Steel Pipes Suppliers, EN 10083-2 C45E Carbon Steel Pipes Stockists, EN 10083-2 C45E Carbon Steel Pipes Exporters

EN 10083-2 C45E Carbon Steel Pipes Manufacturers In India, EN 10083-2 C45E Carbon Steel Pipes Suppliers In India, EN 10083-2 C45E Carbon Steel Pipes Stockists In India, EN 10083-2 C45E Carbon Steel Pipes Exporters In India

1.0576 material and S355J2H Square Tube supplier in India

EN 10083-2 C45E Carbon Steel Pipes Manufacturers in Mumbai, EN 10083-2 C45E Carbon Steel Pipes Suppliers in Mumbai, EN 10083-2 C45E Carbon Steel Pipes Stockists in Mumbai, EN 10083-2 C45E Carbon Steel Pipes Exporters in Mumbai

EN 10083-2 C45 is a Euronorm Standards Quenched and tempered steels. It is one such variant that delivers different piping requirements in different industries and has proven its worth through its substantial quality and ability to be used in multiple applications. It is easy to spot and distinguish as it has a dull appearance similar to a matte finish. It looks like a cast iron pot and is not shiny. It composition is made of iron and carbon but it has more of carbon content and this higher carbon content gives it unique characteristics, which includes more malleability and durability. It also has a better heat distribution and lower melting point. All these features make it useful in a number of industries and has a number of commercial applications in different industrial sectors.

EN 10083-2 C45E has good mechanical property, good formability and excellent cutability performance, which is widely useful in various industries, such as bridge construction, architecture, marine craft, heavy machine and other structure parts. It is a structural steel grade which provides a good tensile and yield strength which is also used in bolt, nut and lever etc.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of EN 10083-2 C45E Carbon Steel Pipes

Standard	AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe
EN 10083-2 Grade C22 Seamless Pipe Size	4 to 219mm W. T.: 0.5 to 20mm
Carbon Steel EN 10083-2 Grade C22R Welded Pipe Size	5.0 mm – 1219.2 mm
Steel C45 En 10083-2 EFW Pipe size	5.0 mm – 1219.2 mm
Steel Bs En 10083-2 Tube Swg & Bwg	10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
Din EN 10083-2 Grade C22R Pipe Schedule	SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
En 10083-2 C40 Steel Seamless Tube Size	3.35 mm OD To 101.6 mm OD
Steel Bs En 10083-2 Welded Tube Size	6.35 mm OD To 152 mm OD
Carbon Steel EN 10083-2 Grade C22 Swg & Bwg	10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
Carbon Steel En 10083-2 C45e Tube wall thickness	0.020" –0.220", (special wall thicknesses available)
Carbon EN 10083-2 Grade C45 Steel Length	Single Random, Double Random, Standard & Cut length Pipe & Tube
Iso EN 10083-2 Grade 28MN6 Carbon Steel Finish	Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF
EN 10083-2 Gr C45 Form	Round, Hydraulic, 'U' bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc
Carbon Steel EN 10083-2 Grade C22R Type	Welded, Seamless, ERW, EFW, Fabricated Pipe, 'U' bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc
EN 10083-2 Gr C35 Carbon Steel End	Plain End, Beveled End, Treaded Pipe & Tube
EN 10083-2 Grade C22 Marking	All En 10083-2 Material are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer's request.)
EN 10083-2 Grade C40 Application	Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube
Steel C45 En 10083-2 Value Added Service	Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc.
CS EN 10083-2 Grade C40 Specialize in	Carbon Steel En 10083-2 C45e Large Diameter Pipe EN 10083-2 Gr C35 Carbon Steel Capillary Tube BS EN 10083-2 Grade C35 Heat Exchanger & En 10083-2 C22e tube Condenser Tube
Material Test Certificates (MTC)	Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Heat Treatment Charts, EN 10083-2 Gr C45 Pipe HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP)
Manufacturers of EN 10083-2 Grade C40 Pipe	Kobe Special Tube, Japan Sumitomo Metals, Japan Nippon Steel Corporation, Japan Sanyo Special Steel, Japan Tubacex Tubos Inoxidables S.A., Spain Schoeller Bleckmann, Austria Seah Steel Corporation, Korea

Chemical Properties of EN 10083-2 C45E Carbon Steel Pipes

Carbon	Silicon	Manganese	Phosphorous	Sulphur	Molybdenum	Nickel	Chromium	Copper	Others
0.37-0.44	max 0.40	0.50-0.80	0.045	0.045	max 0.10	max 0.40	max 0.40	–	–
Grade	C	Si	Mn	P	S	Cr	Ni	Mo	Cr + Mo + Ni
max.	max.	max.	max.	max.	max.	max.	max.	max.
C22E1)	0,17 - 0,24	max. 0,40	0,40 - 0,70	0.045	0.045	max. 0,40	0.40	max. 0,10	0.63
C251)	0,22 - 0,29	0,10 - 0,40	0,40 - 0,70	0.045	0.045	max. 0,40	0.40	max. 0,10	0.63
C301)	0,27 - 0,34	0,10 - 0,40	0,50 - 0,80	0.045	0.045	max. 0,40	0.40	max. 0,10	0.63
C351)	0,32 - 0,39	0,10 - 0,40	0,50 - 0,80	0.045	0.045	max. 0,40	0.40	max. 0,10	0.63
C401)	0,37 - 0,44	0,10 - 0,40	0,50 - 0,80	0.045	0.045	max. 0,40	0.40	max. 0,10	0.63
C451)	0,42 - 0,50	0,10 - 0,40	0,50 - 0,80	0.045	0.045	max. 0,40	0.40	max. 0,10	0.63
C501)	0,47 - 0,55	0,10 - 0,40	0,60 - 0,90	0.045	0.045	max. 0,40	0.40	max. 0,10	0.63
C551)	0,52 - 0,60	0,10 - 0,40	0,60 - 0,90	0.045	0.045	max. 0,40	0.40	max. 0,10	0.63
C601)	0,57 - 0,65	0,10 - 0,40	0,60 - 0,90	0.045	0.045	max. 0,40	0.40	max. 0,10	0.63
34CrMo4	0,30 - 0,37	0,10 - 0,40	0,60 - 0,90	0.025	0.035	0,90 - 1,20	-	0,15 - 0,30	-
42CrMo4	0,38 - 0,45	0,10 - 0,404)	0,60 - 0,90	0.025	0.035	0,90 - 1,20	-	0,15 - 0,30	-
50CrMo4	0,46 - 0,54	0,10 - 0,404)	0,50 - 0,80	0.025	0.035	0,90 - 1,20	-	0,15 - 0,30	-
C67S	0,65 - 0,73	0,15 - 0,35	0,60 - 0,90	0.025	0.025	max. 0,40	0.40	max. 0,10	-
C75S	0,70 - 0,80	0,15 - 0,35	0,60 - 0,90	0.025	0.025	max. 0,40	0.40	max. 0,10	-
51CrV42)	0,47 - 0,55	max. 0,40	0,70 - 1,10	0.025	0.025	0,90 - 1,20	0.40	max. 0,10	-
58CrV43)	0,55 - 0,62	max. 0,40	0,70 - 1,10	0.025	0.025	0,90 - 1,20	-	-	-

Mechanical Properties of EN 10083-2 C45E Carbon Steel Pipes

Yield Strength		Tensile Strength			Elongation A5 min
MPa min	ksi min	MPa min	MPa min	ksi min	Percentage
		580	–	–	16

Equivalent Grade of EN 10083-2 C45E Carbon Steel Pipes

Europe	Material no.	DE	FR	IT	US	JP	FK1)
DIN EN ISO	DIN	NAF	UNI	SAE	JIS G 4051,
683-1 683-2 683-3	172003) 172043)	35-5523) 37-502	6403, 8893, 7356	J 403, J 404	JIS G 5111
C22E2)	1.1151	C22	C 20	-	1023	S 20 C, S 22 C	A
C25	1.0406	C25	-	-	1025	S 25 C	A
C30	1.0528	-	C 30	C30	1030	S 30 C	B
C35 + C35E	1.1181	C35	C 35	C35	1035	S 35 C	B
C40 + C40E	1.0511	C40	C 40	-	1038, 1040	S 40 C	B
C45 + C45E	1.1191	C45	C 45	C45	1042, 1045	S 45 C	B
C50 + C50E	1.0540	C50	C 50	-	1049, 1050	S 50 C	B
C55 + C55E	1.0535	C55	C 55	C55	1055	S 55 C	C
C60 + C60E	1.0601	C60	C 60	C60	1060	S 58 C	C
34CrMo4	1.7220	34 Cr Mo 4	34 CD 4	34CrMo4	4130	SCM432	C
42CrMo4	1.7225	-	42 CD 4	42CrMo4	4140	SCM440	D
50CrMo4	1.7228	50CrMo4	50 CD 4	42CrMo4	4150	SCM445	D
EN 10132-4	DIN 172223)	NFA 37-502, 35-571	UNI 3545	SAE J 403, J 404	JIS G 3311
C67S	1.1231	C 67	XC 68	-	1070	S 70 CM	D
C75S	1.1248	C 75	XC 75	-	1074	-	D
51CrV4	1.8159	50 Cr V 4	50 CV 4	50 CrV 4	6150	SUP 10 M	D
58CrV42)	1.8161	-	-	-	-	-	D
