EN 10216-1 P235tr2 Alloy Steel Pipes

EN 10216-1 P235tr2 Alloy Steel Pipes, EN 10216-1 P235tr2 Alloy Steel Pipes Manufacturers, EN 10216-1 P235tr2 Alloy Steel Pipes Suppliers, EN 10216-1 P235tr2 Alloy Steel Pipes Stockists, EN 10216-1 P235tr2 Alloy Steel Pipes Exporters

EN 10216-1 P235tr2 Alloy Steel Pipes Manufacturers In India, EN 10216-1 P235tr2 Alloy Steel Pipes Suppliers In India, EN 10216-1 P235tr2 Alloy Steel Pipes Stockists In India, EN 10216-1 P235tr2 Alloy Steel Pipes Exporters In India

Low Alloy P235tr1 Seamless steel tubes supplier in India

EN 10216-1 P235tr2 Alloy Steel Threaded Pipe in Mumbai, EN 10216-1 P235tr2 Alloy Steel High Pressure Pipe Manufacturers in Mumbai, EN 10216-1 P235tr2 Alloy Steel Grooved Pipe Suppliers in Mumbai, EN 10216-1 P235tr2 Alloy Steel Marine Exhaust Pipe Exporters in Mumbai, EN 10216-1 P235tr2 Alloy Steel Large Diameter Seamless Pipe Stockists in Mumbai.EN 10216-1 P235tr2 Alloy Steel Pipes Manufacturers in Mumbai, EN 10216-1 P235tr2 Alloy Steel Pipes Suppliers in Mumbai, EN 10216-1 P235tr2 Alloy Steel Pipes Stockists in Mumbai, EN 10216-1 P235tr2 Alloy Steel Pipes Exporters in Mumbai

EN 10216-1 P235tr2 standard specifies Seamless steel tubes for pressure purposes. It is used for manufacturing pipeline, vessel, equipment, pipe fittings. The composition of P235tr2 Alloy Steel material makes it ideal for applications where elevated working temperatures are the norm and the material is used by fabricators throughout the oil, gas and petrochemical industry. EN 10216-1 P235tr2 Alloy Steel Seamless Pipe are used for producing storage tanks of heat-resistant steels used in boiler-making, tool-making and for constructing pressure reservoirs and high pressure and are simultaneously used to have summarized load and special conditions.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Chemical Properties of EN 10216-1 P235tr2 Alloy Steel Pipes

Steel grades	CHEMICAL COMPOSITION (LADLE ANALYSIS)
Steel grades	C% max	Si% max	Mn% max	P% max	S% max	Cr% max	Mo% max	Ni% max	Al. cał% min	Cu% max	Nb% max	Ti% max	V% max	Cr + Cu+ Mo +Ni % MAX
P195TR1	0,13	0,35	0,70	0,025	0,020	0,030	0,08	0,030	-	0,030	0,010	0,04	0,02	0,70
P195TR2	0,13	0,35	0,70	0,025	0,020	0,030	0,08	0,030	0,02	0,030	0,010	0,04	0,02	0,70
P235TR1	0,16	0,35	1,20	0,025	0,020	0,030	0,08	0,030	-	0,030	0,010	0,04	0,02	0,70
P235TR2	0,16	0,35	1,20	0,025	0,020	0,030	0,08	0,030	0,02	0,030	0,010	0,04	0,02	0,70
P265TR1	0,20	0,40	1,40	0,025	0,020	0,030	0,08	0,030	-	0,030	0,010	0,04	0,02	0,70
P265TR2	0,20	0,40	1,40	0,025	0,020	0,030	0,08	0,030	0,02	0,030	0,010	0,04	0,02	0,7

Mechanical Properties of EN 10216-1 P235tr2 Alloy Steel Pipes

Pipe types	Steel grades	Mechanical properties							Resilience
		Upper yield limit Re min for wall thickness T mm			Tensile strength Rm	Elongation A min			Minimum energy average absorbed KV J at the temperature of 0°C
		T<\=16	16<T<\=40	40<T<\=60	Tensile strength Rm	Elongation A min			1		t
		MPa	MPa	MPa	MPa	1		t	0	-10		0
Line pipes P195TR1, P195TR2, P235TR1, P235TR2, P265TR1, P265TR2	P195TR1	195	185	175	320-440	27	25		-	-		-
	P195TR2	195	185	175	320-440	27	25		40	28		27
	P235TR1	235	225	215	360-500	25	23		-	-		-
	P235TR2	235	225	215	360-500	25	23		40	28		27
	P265TR1	265	255	245	410-570	21	19		-	-		-
	P265TR2	265	255	245	410-570	21	19		40	28		27

Tests of EN 10216-1 P235tr2 Alloy Steel Seamless Pipe

Inspection and test type		Test frequency
Mandatory tests	Ladle analysis	One ladle
	Tensile testing	One per every tested batch
	Resilience testing at the temperature of 0ºC	One per every tested batch
	Tightness testing	Every pipe
	Dimensional testing	-
	Visual inspection	-
Optional tests	Ladle analysis	One ladle
	Resilience testing on longitudinal samples at the temperature of -10ºC	One per every tested batch
	Wall thickness measurements at a distance from pipe ends	-
	Non-destructive testing in order to identify any longitudinal discontinuity	Every pipe

Basic Type of EN Pipes

EN 10216-1 P235tr2 Alloy Steel Pipe

EN 10216-1 P235tr2 Alloy Steel Seamless Pipe

EN 10216-1 P235tr2 Alloy Steel Welded Pipe

P235tr2 Alloy Steel Tube

EN 10216-1 P235tr1 Tubing

EN 10216 Seamless Steel Tubes
