EN 10216-2 P235GH TC1 Alloy Steel Pipes

EN 10216-2 P235GH TC1 Alloy Steel Pipes, EN 10216-2 P235GH TC1 Alloy Steel Pipes Manufacturers, EN 10216-2 P235GH TC1 Alloy Steel Pipes Suppliers, EN 10216-2 P235GH TC1 Alloy Steel Pipes Stockists, EN 10216-2 P235GH TC1 Alloy Steel Pipes Exporters

EN 10216-2 P235GH TC1 Alloy Steel Pipes Manufacturers In India, EN 10216-2 P235GH TC1 Alloy Steel Pipes Suppliers In India, EN 10216-2 P235GH TC1 Alloy Steel Pipes Stockists In India, EN 10216-2 P235GH TC1 Alloy Steel Pipes Exporters In India

1.0576 material and S355J2H Square Tube supplier in India

EN 10216-2 P235GH TC1 Alloy Steel Pipes Manufacturers in Mumbai, EN 10216-2 P235GH TC1 Alloy Steel Pipes Suppliers in Mumbai, EN 10216-2 P235GH TC1 Alloy Steel Pipes Stockists in Mumbai, EN 10216-2 P235GH TC1 Alloy Steel Pipes Exporters in Mumbai

EN 10216-2 P235GH is an European specified steel for use in boilers, heat exchangers and pressure vessels. It is heat-resistant non-alloy quality steel for application in steam boiler and pressure vessel construction. The application maximum temperature is approx. 400 °C. EN 10216-2 P235GH TC1 Alloy Steel Seamless Tubes composition of it makes it ideal for applications where elevated working temperatures are the norm and the material is used by fabricators throughout the petrochemical, oil and gas industry. It has properties such as good corrosion resistance at high strength, good sulfide stress corrosion resistance, and higher resistance to chloride stress corrosion cracking and can be easy to weld and conform.

EN 10216-2 P235GH TC1 is also a key consumable material for boilers and pressurized vessels. However, any manufacturer who is using this material for any application of intense pressure should work out all possibilities in the design calculations.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of EN 10216-2 P235GH TC1 Alloy Steel Pipes

We can also cut, thread, and groove EN 10216-2 Grade P235GH Alloy Steel Pipe to meet your specifications. Pipe Dimension ANSI/ ASME B36.19, B36.10, B2.1
P355nl1 En 10216-3 Pipe Schedule	SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Bs EN 10216-2 Grade P265GH Alloy Steel Tube Swg & Bwg	10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
Alloy Steel EN 10216-1 Grade P265TR1 Seamless Tube Size	3.35 mm OD To 101.6 mm OD
Standard	AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe
Bs EN 10216-2 Grade P265GH Alloy Steel Welded Tube Size	6.35 mm OD To 152 mm OD
Steel En 10216 Seamless Pipe Size	4 to 219mm W. T.: 0.5 to 20mm
EN 10216-1 Grade P235TR1 Alloy Steel EFW Pipe size	5.0 mm – 1219.2 mm
Alloy Steel En 10216-5 Pipe End	Plain End, Beveled End, Treaded Pipe & Tube
En 10216 Material Welded Pipe Size	5.0 mm – 1219.2 mm
EN 10216-1 Grade P235TR1 Tubes Swg & Bwg	10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg.
Alloy Steel EN 10216-2 Grade P235GH Tubes Application	Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube
En 10216 Material Type	Welded, Seamless, ERW, EFW, Fabricated Pipe, 'U' bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc
EN 10216-3 Grade P275NL2 Alloy Steel Specialize in	Astm A312 En 10216-5 Condenser Tube Alloy Steel En 10216-5 Capillary Tube EN 10216-4 Grade P215NL Alloy Steel Large Diameter Pipe EN 10216-2 Grade P265GH Tubes Heat Exchanger
Steel En 10216 Marking	All EN 10216-2 Grade P235GH Seamless Steel Tube are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer's request.)
EN 10216-1 Grade P235TR1 Alloy Steel Value Added Service	Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc.
En P265nl Grade 10216-4 Finish	Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF
EN 10216-4 Grade P215NL Alloy Steel Tube wall thickness	0.020" –0.220", (special wall thicknesses available)
Material Test Certificates (MTC)	Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Heat Treatment Charts, AS Grade X11CrMo5+NT1 Pipe HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP)
Manufacturers of Alloy Steel EN 10216-2 Grade P235GH Pipe	Schoeller Bleckmann, Austria Tubacex Tubos Inoxidables S.A., Spain Sanyo Special Steel, Japan Kobe Special Tube, Japan Seah Steel Corporation, Korea Nippon Steel Corporation, Japan Sumitomo Metals, Japan
EN 10216-2 Grade P235GH Alloy Steel Length	Single Random, Double Random, Standard & Cut length Pipe & Tube
AS Grade X11CrMo5+NT1 Form	Round, Hydraulic, 'U' bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc

Chemical Properties of EN 10216-2 P235GH TC1 Alloy Steel Pipes

Products	Carbon	Silicon	Manganese	Phosphorous	Sulphur	Molybdenum	Nickel	Chromium	Copper	Others
EN 10216-1 Grade P195TR1	max 0.13	max 0.70	0.025	0.02	max 0.30	max 0.30	max 0.08	max 0.30	–	V max 0.02 Ti max 0.04
EN 10216-1 Grade P195TR2	max 0.13	max 0.70	0.025	0.015	max 0.30	max 0.30	max 0.08	max 0.30	–	V max 0.02 Ti max 0.04 Al min 0.02
EN 10216-1 Grade P235TR1	max 0.16	max 1.20	0.025	0.02	max 0.30	max 0.30	max 0.08	max 0.30	–	V max 0.02 Ti max 0.04
EN 10216-1 Grade P235TR2	max 0.16	max 1.20	0.025	0.015	max 0.30	max 0.30	max 0.08	max 0.30	–	V max 0.02 Ti max 0.04 Al min 0.02
EN 10216-1 Grade P265TR1	max 0.20	max 1.40	0.025	0.02	max 0.30	max 0.30	max 0.08	max 0.30	–	V max 0.02 Ti max 0.04
EN 10216-1 Grade P265TR2	max 0.20	max 1.40	0.025	0.015	max 0.30	max 0.30	max 0.08	max 0.30	–	V max 0.02 Ti max 0.04 Al min 0.02
EN 10216-2 Grade X10CrMoVNb9-1	0.08-0.12	0.20-0.50	0.30-0.60	0.02	0.005	0.85-1.05	max 0.40	8.00-9.00	max 0.30	V0.18-0.25 Nb0.06-0.10 N0.03-0.07
EN 10216-2 Grade P265GH	max 0.20	max 0.40	max 1.40	0.025	0.01	max 0.08	max 0.30	max 0.30	max 0.30	V max 0.02 Ti max 0.04 Al min 0.020
EN 10216-2 Grade 14MoV6-3	0.10-0.18	0.10-0.35	0.40-0.70	0.025	0.01	0.50-0.70	–	0.30-0.60	–	V0.22-0.28
EN 10216-2 Grade 7CrWVMoNb9-6	0.04-0.10	max 0.5	0.10-0.60	0.03	0.01	0.05-0.30	–	1.90-2.60	–	W1.45-1.75 V0.20-0.30 Al max 0.030 Nb0.02-0.08
EN 10216-2 Grade 7CrMoVTiB10-10	0.05-0.10	0.15-0.45	0.30-0.70	0.02	0.01	0.90-1.10	–	2.20-2.60	–	V0.02-0.03 Al max 0.020 B0.015-0.070 N max 0.010
EN 10216-2 Grade 16Mo3	0.12-0.20	0.15-0.35	0.40-0.90	0.025	0.01	0.25-0.35	–	–	–	Al max 0.040
EN 10216-2 Grade 10CrMo5-5	max 0.15	0.50-1.00	0.30-0.60	0.025	0.01	0.45-0.65	max 0.30	1.00-1.50	max 0.30	Al max 0.040
EN 10216-2 Grade 13CrMo4-5	0.10-0.17	0.15-0.35	0.40-0.70	0.025	0.01	0.40-0.60	–	0.70-1.15	–	Al max 0.040
EN 10216-2 Grade 11CrMo9-10+QT	0.08-0.15	max 0.5	0.40-0.80	0.025	0.01	0.90-1.10	max 0.30	2.0-2.5	max 0.30	Al max 0.040
EN 10216-2 Grade 25CrMo4	0.22-0.29	max 0.4	0.6-0.9	0.035	0.01	0.15-0.30	–	0.9-1.2	–	–
EN 10216-2 Grade X11CrMo5+I	0.08-0.15	0.15-0.50	0.30-0.60	0.025	0.01	0.45-0.65	–	4.00-6.00	max 0.30	–
EN 10216-2 Grade X11CrMo5+NT1	0.08-0.15	0.15-0.50	0.30-0.60	0.025	0.01	0.45-0.65	–	4.00-6.00	max 0.30	–
EN 10216-2 Grade X11CrMo5+NT2	0.08-0.15	0.15-0.50	0.30-0.60	0.025	0.01	0.45-0.65	–	4.00-6.00	max 0.30	–
EN 10216-2 Grade P195GH	max 0.13	max 0.35	max 0.70	0.025	0.01	max 0.08	max 0.30	max 0.30	max 0.30	V max 0.02 Ti max 0.04 Al min 0.020
EN 10216-2 Grade P235GH	max 0.16	max 0.35	max 1.20	0.025	0.01	max 0.08	max 0.30	max 0.30	max 0.30	V max 0.02 Ti max 0.04 Al min 0.020
EN 10216-3 Grade P460NH	max 0.20	max 0.60	1.00-1.70	0.025	0.01	max 0.10	max 0.80	max 0.30	max 0.70	V max 0.20 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.22
EN 10216-3 Grade P460NL1	max 0.20	max 0.60	1.00-1.70	0.025	0.008	max 0.10	max 0.80	max 0.30	max 0.70	V max 0.20 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.22
EN 10216-3 Grade P460NL2	max 0.20	max 0.60	1.00-1.70	0.025	0.005	max 0.10	max 0.80	max 0.30	max 0.70	V max 0.20 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.22
EN 10216-3 Grade P275NL1	max 0.16	max 0.40	0.50-1.50	0.025	0.008	max 0.08	max 0.50	max 0.30	max 0.30	V max 0.05 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.05
EN 10216-3 Grade P275NL2	max 0.16	max 0.40	0.50-1.50	0.025	0.005	max 0.08	max 0.50	max 0.30	max 0.30	V max 0.05 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.05
EN 10216-3 Grade P355N	max 0.20	max 0.50	0.90-1.70	0.025	0.02	max 0.08	max 0.50	max 0.30	max 0.30	V max 0.10 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.12
EN 10216-3 Grade P355NH	max 0.20	max 0.50	0.90-1.70	0.025	0.01	max 0.08	max 0.50	max 0.30	max 0.30	V max 0.10 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.12
EN 10216-3 Grade P355NL1	max 0.18	max 0.50	0.90-1.70	0.025	0.008	max 0.08	max 0.50	max 0.30	max 0.30	V max 0.10 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.12
EN 10216-3 Grade P355NL2	max 0.18	max 0.50	0.90-1.70	0.025	0.005	max 0.08	max 0.50	max 0.30	max 0.30	V max 0.10 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.12
EN 10216-3 Grade P460N	max 0.20	max 0.60	1.00-1.70	0.025	0.02	max 0.10	max 0.80	max 0.30	max 0.70	V max 0.20 Nb max 0.05 Ti max 0.04 Al min 0.020 Nb+Ti+V max 0.22
EN 10216-4 Grade P215NL	max 0.15	max 0.35	0.40-1.20	0.03	0.01	max 0.08	max 0.30	max 0.30	max 0.30	V max 0.020 Nb max 0.010 Ti max 0.040 Al min 0.020
EN 10216-4 Grade P265NL	max 0.20	max 0.40	0.60-1.40	0.03	0.01	max 0.08	max 0.30	max 0.30	max 0.30	V max 0.020 Nb max 0.010 Ti max 0.040 Al min 0.020

Mechanical Properties of EN 10216-2 P235GH TC1 Alloy Steel Pipes

Products	Yield Strength		Tensile Strength			Elongation A5 min
	MPa min	ksi min	MPa min	MPa min	ksi min	Percentage
EN 10216-1 Grade P195TR1			320	440	–	27
EN 10216-1 Grade P195TR2			320	440	–	27
EN 10216-1 Grade P235TR1			360	500	–	25
EN 10216-1 Grade P235TR2			360	500	–	25
EN 10216-1 Grade P265TR1			410	570	–	21
EN 10216-1 Grade P265TR2			410	570	–	21
EN 10216-2 Grade X10CrMoVNb9-1			630	830	–	19
EN 10216-2 Grade P265GH			410	570	–	23
EN 10216-2 Grade 14MoV6-3			460	610	–	20
EN 10216-2 Grade 7CrWVMoNb9-6			510	470	–	20
EN 10216-2 Grade 7CrMoVTiB10-10			565	840	–	17
EN 10216-2 Grade 16Mo3			450	600	–	22
EN 10216-2 Grade 10CrMo5-5			410	560	–	22
EN 10216-2 Grade 13CrMo4-5			440	590	–	22
EN 10216-2 Grade 11CrMo9-10+QT			540	680	–	20
EN 10216-2 Grade 25CrMo4			900	–	–	12
EN 10216-2 Grade X11CrMo5+I			430	580	–	22
EN 10216-2 Grade X11CrMo5+NT1			480	640	–	20
EN 10216-2 Grade X11CrMo5+NT2			570	740	–	18
EN 10216-2 Grade P195GH			320	440	–	27
EN 10216-2 Grade P235GH			360	500	–	25
EN 10216-3 Grade P460NH			560	730	–	19
EN 10216-3 Grade P460NL1			560	730	–	19
EN 10216-3 Grade P460NL2			560	730	–	19
EN 10216-3 Grade P275NL1			390	530	–	24
EN 10216-3 Grade P275NL2			390	530	–	24
EN 10216-3 Grade P355N			490	650	–	22
EN 10216-3 Grade P355NH			490	650	–	22
EN 10216-3 Grade P355NL1			490	650	–	22
EN 10216-3 Grade P355NL2			490	650	–	22
EN 10216-3 Grade P460N			560	730	–	19
EN 10216-4 Grade P215NL			360	480	–	25
EN 10216-4 Grade P265NL			410	570	–	24

Equivalent Grade of EN 10216-2 P235GH TC1 Alloy Steel Pipes

Products	DIN	En	BS	NFA	ASTM	ASME
EN 10216-1 Grade P195TR1	–	EN 10216-1 Grade P195TR1	–	–	–	–
EN 10216-1 Grade P195TR2	–	EN 10216-1 Grade P195TR2	–	–	–	–
EN 10216-1 Grade P235TR1	–	EN 10216-1 Grade P235TR1	–	–	–	–
EN 10216-1 Grade P235TR2	–	EN 10216-1 Grade P235TR2	–	–	–	–
EN 10216-1 Grade P265TR1	–	EN 10216-1 Grade P265TR1	–	–	–	–
EN 10216-1 Grade P265TR2	–	EN 10216-1 Grade P265TR2	–	–	–	–
EN 10216-2 Grade X10CrMoVNb9-1	–	EN 10216-2 Grade X10CrMoVNb9-1	–	–	–	–
EN 10216-2 Grade P265GH	–	EN 10216-2 Grade P265GH	–	–	–	–
EN 10216-2 Grade 14MoV6-3	–	EN 10216-2 Grade 14MoV6-3	–	–	–	–
EN 10216-2 Grade 7CrWVMoNb9-6	–	EN 10216-2 Grade 7CrWVMoNb9-6	–	–	–	–
EN 10216-2 Grade 7CrMoVTiB10-10	–	EN 10216-2 Grade 7CrMoVTiB10-10	–	–	–	–
EN 10216-2 Grade 16Mo3	–	EN 10216-2 Grade 16Mo3	–	–	–	–
EN 10216-2 Grade 10CrMo5-5	–	EN 10216-2 Grade 10CrMo5-5	–	–	–	–
EN 10216-2 Grade 13CrMo4-5	–	EN 10216-2 Grade 13CrMo4-5	–	–	–	–
EN 10216-2 Grade 11CrMo9-10+QT	–	EN 10216-2 Grade 11CrMo9-10+QT	–	–	–	–
EN 10216-2 Grade 25CrMo4	DIN 17200 Grade 25CrMo4	EN 10216-2 Grade 25CrMo4	NFA EN . Grade 25CrMo4	–	–	–
EN 10216-2 Grade X11CrMo5+I	–	EN 10216-2 Grade X11CrMo5+I	–	–	–	–
EN 10216-2 Grade X11CrMo5+NT1	–	EN 10216-2 Grade X11CrMo5+NT1	–	–	–	–
EN 10216-2 Grade X11CrMo5+NT2	–	EN 10216-2 Grade X11CrMo5+NT2	–	–	–	–
EN 10216-2 Grade P195GH	–	EN 10216-2 Grade P195GH	–	–	–	–
EN 10216-2 Grade P235GH	–	EN 10216-2 Grade P235GH	–	–	–	–
EN 10216-3 Grade P460NH	DIN 17178/17179 Grade FGP 47 W	EN 10216-3 Grade P460NH	–	–	–	–
EN 10216-3 Grade P460NL1	DIN 17178/17179 Grade FGP 47 T	EN 10216-3 Grade P460NL1	–	ASTM A 381 Grade Y 65	ASME SA 381 Grade Y 65	–
EN 10216-3 Grade P460NL2	DIN 17178/17179 Grade FGP 47 E	EN 10216-3 Grade P460NL2	–	–	–	–
EN 10216-3 Grade P275NL1	DIN 17179 Grade FGP 28 T	EN 10216-3 Grade P275NL1	NFA A49-2452) Grade TS 42-BT	ASTM A 662 Grade B	ASME SA 662 Grade B	–
EN 10216-3 Grade P275NL2	DIN 17179 Grade FGP 28 E	EN 10216-3 Grade P275NL2	–	ASTM A 707 Grade L2, Class 1	ASME SA 707 Grade L2, ClSAss 1	–
EN 10216-3 Grade P355N	DIN 17179 Grade FGP 36	EN 10216-3 Grade P355N	NFA A 49-326 Grade TU 52-BT	ASTM A381 Grade Y 52	ASME SA381 Grade Y 52	–
EN 10216-3 Grade P355NH	DIN 17179 Grade FGP 36 W	EN 10216-3 Grade P355NH	NFA A 36-2051) Grade A 52 FP	ASTM A 662 Grade C	ASME SA 662 Grade C	–
EN 10216-3 Grade P355NL1	DIN 17179 Grade FGP 36 T	EN 10216-3 Grade P355NL1	NFA A 36-2071) Grade A 510 FP 1	ASTM A 707 Grade L2,Class 2	ASME SA 707 Grade L2,ClSAss 2	–
EN 10216-3 Grade P355NL2	DIN 17179 Grade FGP 36 E	EN 10216-3 Grade P355NL2	–	–	–	–
EN 10216-3 Grade P460N	DIN 17178/17179 Grade FGP 47	EN 10216-3 Grade P460N	–	ASTM A 225 Grade C	ASME SA 225 Grade C	–
EN 10216-4 Grade P215NL	–	EN 10216-4 Grade P215NL	–	–	–	–
EN 10216-4 Grade P265NL	–	EN 10216-4 Grade P265NL	–	–	–	–

Basic Type of EN Pipes

EN 10216-2 P235GH TC1 Alloy Steel Pipe

EN 10216-2 P235GH TC1 Alloy Steel Seamless Pipe

EN 10216-2 P235GH TC1 Alloy Steel Welded Pipe

EN 10216-2 P235GH Tubing

EN 10216-2 P235GH TC1 Tube

1.0345 p235gh Tube
