The EN 10219 S235JRH Steel Grade RHS tubes are utilized in various industries due to its impressive list of features. For instance, this grade of Carbon Steel EN 10219 S235JRH Rectangular Tube offers many good properties such as good conductivity, outstanding resistivity, while being sturdy in nature. Also, since the carbon grade EN 10219 S235JRH tubes produced in our factory are manufactured from good quality raw materials, it tends to be durable. The fore mentioned properties along with the long service life of EN 10219 S235JRH Carbon Steel Round Tube make it an attractive, yet cost saving option for our clients based in industries such as several petrochemical companies as well as those industries in the energy sector.
Typically, this grade of carbon steel based EN 10219 S235JRH tubes are considered to be standard issue for purposes such as general metal and Engineering. In the field of engineering, the Steel EN 10219 S235JRH Hot Finished Structural Hollow Sections is often used in civil engineering and bridge engineering as well as for water engineering.
All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!
Specification Schedule of EN 10219 S235JRH Carbon Steel Pipes
| Specification |
- CE (EN 1090) certified.
- Consistent quality
- Cut to size
|
| Standard |
BS EN 10219 – Cold Formed Rectangular Hollow Sections Pipes |
| Grade |
S235JRH |
| RHS (Rectangular Hollow Sections) Sizes in mm |
10 x 15mm / 150 x50 / 300 x400 / 600 x550 |
| Wall Thickness |
0.5 – 25mm |
| Length |
6000-14000 mm |
| Type |
Seamless/ Welded / ERW / EFW |
| Dimensional Tolerances |
Thickness : (All sizes +/- 10%) |
| Circular Dimension Range |
26.9 – 323.9 mm |
| Square Dimension Range |
25×25 - 300×300 mm |
| Rectangular Dimension Range |
40×20 - 400×200 mm |
| Concavity / Convexity |
1 percent of the size |
| Twist Tolerance |
Maximum 2 mm ± 0.05 mm/m length-measured relative vertical shift of any adjacent corner of the section, measured by keeping one side on flat surface |
| Surface Protection |
Black (Self Coloured uncoated), Varnish/Oil Coating, Pre-Galvanized, Hot Dip Galvanized |
| Delivery conditions |
EN 10219-1:2006 |
| Documents |
EN 10204-2004/3.1, EN 10204-2004/2.2, EN 10204-2004/2.1, CE - mark |
| Application & Uses |
- Metal structures and composite steel and concrete structures
- Suitability for galvanizing
|
Chemical Properties of EN 10219 S235JRH Carbon Steel Pipes
| Steel Grade |
Steel No. |
Chemical Composition Limits (%) |
| C Max. |
Si Max. |
Mn Max. |
P Max. |
S Max. |
N Max. |
| S235JRH |
1.0039 |
0.17 |
– |
1.40 |
0.040 |
0.040 |
0.009 |
| S275J0H |
1.0149 |
0.20 |
– |
1.50 |
0.035 |
0.035 |
0.009 |
| S275J2H |
1.0138 |
0.20 |
– |
1.50 |
0.030 |
0.030 |
– |
| S355J0H |
1.0547 |
0.22 |
0.55 |
1.60 |
0.035 |
0.035 |
0.009 |
| S355J2H |
1.0576 |
0.22 |
0.55 |
1.60 |
0.030 |
0.030 |
– |
| S355K2H |
1.0512 |
0.22 |
0.55 |
1.60 |
0.030 |
0.030 |
– |
Mechanical Properties of EN 10219 S235JRH Carbon Steel Pipes
| Steel Grade |
Steel No. |
Mechanical Properties |
Impact Energy (KV J) |
| Yield Strength (Mpa) |
Tensile Strength (Mpa) |
Elongation (%) |
Test Temperature At Test Temperature of ℃ |
| -20 |
0 |
20 |
| S235JRH |
1.0039 |
235 |
360-510 |
26 |
– |
– |
27 |
| S275J0H |
1.0149 |
275 |
410-560 |
23 |
– |
27 |
– |
| S275J2H |
1.0138 |
275 |
410-560 |
23 |
27 |
– |
– |
| S355J0H |
1.0547 |
355 |
510-680 |
22 |
– |
27 |
– |
| S355J2H |
1.0576 |
355 |
510-680 |
22 |
27 |
– |
– |
| S355K2H |
1.0512 |
355 |
510-680 |
22 |
40 |
– |
– |
Equivalent Grade of EN 10219 S235JRH Carbon Steel Pipes
| DIN |
R St 37-2 |
| EN |
S235JRH |
| Werkstoff |
1.0038 |
Basic Type of EN Pipes
EN 10219 S235JRH Carbon Steel Pipe
EN 10219 S235JRH Hollow Section
En 10219 Din 2395 S235JRH RHS
S235JRH EN 10219 Steel Hot Finished Square Pipe
Carbon Steel EN 10219 S235JRH Rectangular Tube
Cold Formed EN 10219 S235JRH Square Hollow Section
