EN 10217-1 P235TR1 welded steel tubes are used for high temperature service applications. It is a carbon non-alloy steel constructed for primary forming into wrought products. Its specified properties are appropriate for the normalized condition. 1.0254 is the EN numeric designation for this material. P235TR1 is the EN chemical designation. P235TR2 Electric Welded Alloy Steel tubes have a moderately high ductility and a moderately low tensile strength among wrought carbon or non-alloy steels. EN 10217-1 P235TR2 are intended for use in systems for both pressure equipment and pipelines. It is mainly used in boiler, transportation of oil, natural gas, gas, pressure pipe, pipe for ship, structure pipe etc.

All Chhajed products are manufactured under strict process control and monitored throughout the production process. They go through several checks to ensure that the product delivered is of finest quality!

Specification Schedule of EN 10217-1 P235TR1 Alloy Steel Pipes

Steel grades used	EN 10217-1 grades: P195TR1, P235TR1, P265TR2 P195TR2, P235TR2, P265TR2 EN10217-2 grades:P195GH,P235GH,P265GH,16Mo3 EN 10217-3 grades:P275NL1,P355N,P355NH,P460N... EN 10217-4 grades:P215NL,P265NL EN 10217-5 grades: P235GH,P265GH,16Mo3 EN 10217-6 grades:P215NL,P265NL EN 10217-7 grades:1.4301(X5CrNi18-10),1.4404(X5CrNiMo17-12-2)
Dimensions and tolerances	For the outside diameter D219,1 D +/-0,75 % or +/- 6 mm depending on which value is greater. The tolerances applied to wall thickness depend on the wall T For T5 +/-8 % or 2 mm (depending on which value is greater)
Pipe lengths	Pipes with precise lengths are manufactured with the following tolerance values: for D406,4- for pipes 0- 6m -0/+25%- for pipes 6-12m -0/+50%- for pipes longer than 12m -0/to be negotiated
Tightness	Pipes should be subject to water testing (7Mpa) or electromagnetic testing.
Straightness	< 0,0015 of pipe length (below 3mm per every meter of pipe length)
Tests	Mandatory tests: ladle analysis, tensile testing, transverse tensile testing of the weld > 508, tightness testing, dimension verification, visual inspection, NDT of the weld Optional tests: transverse tensile testing of the weld D= 219,1- 508, wall thickness measurement at a distance from pipe ends

Chemical Properties of EN 10217-1 P235TR1 Alloy Steel Pipes

Designation		Chemical composition (% by mass - max unless stated)
Steel name	Steel number	C	Si	Mn	P	S	Cr	Mo	Ni	Cu	N	Others	In 10296-2?
Austenitic steels
X2CrNi18-9	1.4307	0.030	1.00	2.00	0.045	0.015	17.5/19.5	-	8.0/10.0	-	0.11	-	Yes
X2CrNi19-11	1.4306	0.030	1.00	2.00	0.045	0.015	18.0/20.0	-	10.0/12.0	-	0.11	-	Yes
X2CrNiN18-10	1.4311	0.030	1.00	2.00	0.045	0.015	17.0/19.5	-	8.5/11.5	-	0.12/0.22	-	Yes
X5CrNi18-10	1.4301	0.07	1.00	2.00	0.045	0.015	17.0/19.5	-	8.0/10.5	-	0.11	-	Yes
X6CrNiTi18-10	1.4541	0.08	1.00	2.00	0.045	0.015	17.0/19.0	-	9.0/12.0	-	-	Ti 5xC/0.70	Yes
X6CrNiNb18-10	1.4550	0.08	1.00	2.00	0.045	0.015	17.0/19.0	-	9.0/12.0	-	-	Nb 10xC/1.00	Yes
X2CrNiMo17-12-2	1.4404	0.030	1.00	2.00	0.045	0.015	16.5/18.5	2.0/2.5	10.0/13.0	-	0.11	-	Yes
X5CrNiMo17-12-2	1.4401	0.07	1.00	2.00	0.045	0.015	16.5/18.5	2.0/2.5	10.0/13.0	-	0.11	-	Yes
XCrNiMoTi17-12-2	1.4571	0.08	1.00	2.00	0.045	0.015	16.5/18.5	2.00/2.50	10.5/13.5	-	-	Ti 5xC/0.70	Yes
X2CrNiMo17-12-3	1.4432	0.030	1.00	2.00	0.045	0.015	16.5/18.5	2.50/3.00	10.5/13.0	-	0.11	-	Yes
X2CrNiMoN17-13-3	1.4429	0.030	1.00	2.00	0.045	0.015	16.5/18.5	2.50/3.00	11.0/14.0	-	0.12/0.22	-	Yes
X3CrNiMo17-13-3	1.4436	0.05	1.00	2.00	0.045	0.015	16.5/18.5	2.50/3.00	10.5/13.0	-	0.11	-	Yes
X2CrNiMo18-14-3	1.4435	0.030	1.00	2.00	0.045	0.015	17.0/19.0	2.50/3.00	12.5/15.0	-	0.11	-	Yes
X2CrNiMoN17-13-5	1.4439	0.030	1.00	2.00	0.040	0.015	16.5/18.5	4.00/5.00	12.5/14.5	-	0.12/0.22	-	Yes
X2CrNiMo18-15-4	1.4438	0.030	1.00	2.00	0.045	0.015	17.5/19.5	3.00/4.00	13.0/16.0	-	0.11	-	No
X1NiCrMoCu31-27-4	1.4563	0.020	0.70	2.00	0.030	0.010	26.0/28.0	3.00/4.00	30.0/32.0	0.70/1.50	0.11	-	No
X1CrNiMoCu25-20-5	1.4539	0.020	0.70	2.00	0.030	0.010	19.0/21.0	4.00/5.00	24.0/26.0	1.20/2.00	0.15	-	Yes
X1CrNiMoCuN20-18-7	1.4547	0.020	0.70	1.00	0.030	0.010	19.5/20.5	6.00/7.00	17.5/18.5	0.50/1.00	0.18/0.25	-	Yes
X1NiCrMoCuN25-20-7	1.4529	0.020	0.50	1.00	0.030	0.010	19.0/21.0	6.00/7.00	24.0/26.0	0.50/1.50	0.15/0.25	-	No
Austenitic ferritic steels
X2CrNiN23-4	1.4362	0.030	1.00	2.00	0.035	0.015	22.0/24.0	0.10/0.60	3.5/5.5	0.10/0.60	0.05/0.20	-	Yes
X2CrNiMoN22-5-3	1.4462	0.030	1.00	2.00	0.035	0.015	21.0/23.0	2.50/3.50	4.5/6.5	-	0.10/0.22	-	Yes
X2CrNiMoN25-7-4	1.4410	0.030	1.00	2.00	0.035	0.015	24.0/26.0	3.00/4.50	6.0/8.0	-	0.20/0.35	-	Yes
X2CrNiMoCuWN25-7-4	1.4501	0.030	1.00	1.00	0.035	0.015	24.0/26.0	3.00/4.00	6.0/8.0	0.50/1.00	0.20/0.30	W 0.50/1.00	No

Mechanical Properties of EN 10217-1 P235TR1 Alloy Steel Pipes

Tensile properties at RT						Impact properties
Steel grade		Proof Strength		Tensile strength	Elongation		Minimum average of 3 Charpy (J)
		Rp0.2	Rp1.0	Rm	A min (%)		at RT		at -sub-zero temperature1
Steel name	Steel number	MPa	MPa	MPa	long	trans	long	trans	trans
Austenitic steels
X2CrNi18-9	1.4307	180	215	470-670	40	35	100	60	60
X2CrNi19-11	1.4306	180	215	460-680	40	35	100	60	60
X2CrNiN18-10	1.4311	270	305	550-760	35	30	100	60	60
X5CrNi18-10	1.4301	195	230	500-700	40	35	100	60	60
X6CrNiTi18-10	1.4541	200	235	500-730	35	30	100	60	60
X6CrNiNb18-10	1.4550	205	240	510-740	35	30	100	60	60
X2CrNiMo17-12-2	1.4404	190	225	490-690	40	30	100	60	60
X5CrNiMo17-12-2	1.4401	205	240	510-710	40	30	100	60	60
XCrNiMoTi17-12-2	1.4571	210	245	500-730	35	30	100	60	60
X2CrNiMo17-12-3	1.4432	190	225	490-690	40	30	100	60	60
X2CrNiMoN17-13-3	1.4429	295	330	580-800	35	30	100	60	60
X3CrNiMo17-13-3	1.4436	205	240	510-710	40	30	100	60	60
X2CrNiMo18-14-3	1.4435	190	225	490-690	40	30	100	60	60
X2CrNiMoN17-13-5	1.4439	285	315	580-800	35	30	100	60	60
X2CrNiMo18-15-4	1.4438	220	250	490-690	35	30	100	60	60
X1NiCrMoCu31-27-4	1.4563	215	245	500-750	40	35	120	90	60
X1CrNiMoCu25-20-5	1.4539	220	250	520-720	35	30	120	90	60
X1CrNiMoCuN20-18-7	1.4547	300	340	650-850	35	30	100	60	60
X1NiCrMoCuN25-20-7	1.4529	300	340	600-800	40	40	120	90	60
Duplex - Austenitic ferritic steels
X2CrNiN23-4	1.4362	400	----	600-820	25	25	120	90	40
X2CrNiMoN22-5-3	1.4462	450	----	700-920	25	20	120	90	40
X2CrNiMoN25-7-4	1.4410	550	----	800-1000	20	20	100	100	40
X2CrNiMoCuWN25-7-4	1.4501	550	----	800-1000	20	20	100	100	40

Equivalent Grade of EN 10217-1 P235TR1 Alloy Steel Pipes

Steel Name	Steel Number	AISI Grade
X2CrNi18-9	1.4307	304L
X5CrNi18-10	1.4301	304
X2CrNiMo17-12-2	1.4404	316L
X6CrNiTi18-10	1.4541	321
X6CrNiMoTi17-12-2	1.4571	316Ti
X2CrNiMo18-15-4	1.4438	317L
X2CrNiMoN22-5-3	1.4462	2205

Basic Type of EN Pipes

EN 10217-1 P235TR1 welded steel tubes

1.0254 st 37.0 Pipe

P235TR2 Electric Welded Alloy Steel tubes

1.0254 st 37.0 Boiler Tube

EN 10217-1 P235TR2 Tube

EN 10217-1 P235TR1 Welded Tube
